High Speed Opto Interface Modules
4 Channel
Optical Isolation between Input & Output
Low input current < 15mA
Wide input voltage range
High speed operation at 200KHz
24V output or open collector output selectable through jumpers
Compatible with PNP and NPN type
Inputs Suitable For PLC and Micro-Controller based Application
| Opto Type | High Speed Upto 200KHz |
| Input Voltage | 3~15V |
| No. Of Channels | 4 |
| Dielectric Strength | 1. Inputs - channel to channel (when isolated) : 100VAC, 50/60 Hz for 1 minute 2. Input to Output : Optical - 500VAC, 50/60 Hz for 1 minute 3. Outputs - channel to channel (when isolated) : 100VAC, 50/60 Hz for 1 minute |
| Features | Optical Isolation between Input & Output Low input current Wide input voltage range High speed operation at 200KHz High speed operation at 200KHz |
| Operating Ambient | 0~55°C, 85% RH |
| Storage Ambient | -20°C to 85°C |
| Termination Input & Output Side | Screw type, for 2.5mm sq. wire |
| Mounting | 35 mm DIN rail |
| Product Code | Description | Certification | Price Factor |
|---|
